Surface Drainage
Comprehensive runoff calculation, drainage infrastructure design and analysis. Calculate catchment runoff, culvert flows, overflows, routing and detention storage through user-defined ponds.
Discover Key Features
- Supports Illudas, Rational, Wallingford and SWMM models
- Simulate dual runoffs with partial flow capture and overflows
- Provision for detention storage at inlets
- Graphically define catchment areas with attributes from DTM
- Attenuate runoff by means of detailed reservoir routing
- Analyses flow, overflow, capacity, velocity and flow depth
- Calculates optimal culvert size, slope, inlet and outlet levels
- Calculates trench volumes, pipe lengths and manhole depths
- Generates layout plan with pipe schedule and long sections
- IH124 or FEH runoff calculation methodology
- Hydraulic routing by Continuity Equation or Time Shift method
They keep adding new and useful features
"After considering the opposition, there is no comparison when it comes to either price or support. Civil Designer Software keep adding new and useful features. The software and support is first class." -Steven Mann, Pr Eng Pr CPM, Engineering Advice & Services (Pty) Ltd.We appreciate the integrated approach
"We particularly appreciate being able to use an integrated design package and the fact that we can call on the team at Civil Designer whenever assistance is required. The team understand technical challenges and provide personalized support. This makes a huge difference." -Marietjie Griffioen, Senior Engineer, SCIP Engineering Group (Pty) Ltd.
Easily adjust your design to meet the specifications stipulated by local standards.
Find out More
Download a detailed pdf brochure
