 Making Calculations
This Tech Tip explains how to use Civil Designer's built in calculation facility.

Whenever the program prompts you to enter a distance, be it diameter, radius, length etc. you can enter that distance as an arithmetic expression, e.g. 120/2.

This expression is calculated when you click on the button, or press [Enter] or your right mouse button after typing the expression, resulting in the correct distance being used.

You can use the following functions:

 * multiply (use the * on the numeric keypad). / divide (use the / on the numeric keypad). - minus (use the - on the numeric keypad). + plus (use the + on the numeric keypad). ^ power, e.g. 10^2 (ten to the power of two). sqrt(x) square root, e.g. sqrt(100) (square root of 100).

The functions sin(x), cos(x), tan(x), asin(x), acos(x), atan(x), atan2(y:x), int(x), abs(x), log(x) and ln(x) are also available.

Standard mathematical hierarchy applies, and brackets can be used to force the sequence of operations. The correct use of brackets when using + and - in combination with * and / is essential.

Last Updated: February 13, 2009
